AUTOMATIC COLD THREAD ROLLING MACHINE

0 out of 5 based on 0 customer ratings
(0 customer reviews)

Our Flat die thread rolling machines allows the production of large and small batches of all kinds of threads that can be cold formed, in the most economically way.

Our Flat die thread rolling machines allows the production of large and small batches of all kinds of threads that can be cold formed, in the most economically way.

Specifications:

Model  No. FDTRM-1 FDTRM-2 FDTRM-3 FDTRM-4 FDTRM-5 FDTRM-6 FDTRM-7
Min. Max. Dia Can Be Rolled 1/16″x1/4″ 1/8″x3/8″ 1/8″x1/2″ 1/4″x5/8″ 1/4″x3/4″ 1/4″x7/8″ 3/8″x1″
Max. Length of Thread 2″ 2.1/2″ 3″ 3″ 4″ 4″ 4″
Dimension of Fixed Dia 3″x2″x1″ 5″x2.1/2″x1″ 5″x3″x1″ 6″x3″x1″ 6″x4″x1″ 7″x4″x1″ 8″x4″x1.1/2″
Dimension of Moving Dia 4″x2″x1″ 6″x2.1/2″x1″ 6″x3″x1″ 7″x3″x1″ 7″x4″x1″ 8″x4″x1″ 9″x4″x1.1/2″
Production in Pieces Per Minute 80 60 60 50 30 30 20
Power Required in H.P. 2 3 5 7.5 10 15 20
