PIPE END FACING MACHINE
Pipe End Facing Machine is used to Chamfering and Deburring of the Pipes before Threading operation and Galvanizing. The Job is chamfered from the External, Internal and Front Face Three different tools. The Job remains still and the Facing Head rotates. The Slide manually move towards Facing Head for Chamfering.
Product Description
Pipe End Facing Machine is used to Chamfering and Deburring of the Pipes before Threading operation and Galvanizing. The Job is chamfered from the External, Internal and Front Face Three different tools. The Job remains still and the Facing Head rotates. The Slide manually move towards Facing Head for Chamfering. The Machine mainly consists of the following: –
- Bed
- Head Stock
- Clamping Vice
- Saddle
Specifications:
Model No. IMC-EM- 1/2″ to 1.1/2″
IMC-BM-1/2″ to 4″ Min. Dia of Pipe to be Chamfered 1/2″ N.B. Pipe 1/2″ Max. Dia of Pipe to be Chamfered 1.1/2″ 4″ Cutting Tools Required (HSS 10% Cobalt) 3/8″ 3/8″ Number of Spindle Speeds Two nos. Four nos. Range of Spindle Speeds 37 to 64 RPM 68 to 180 RPM Main Motor 3 H.P. 1440 RPM 3 H.P. 1440 RPM Approx. Wt. of the Machine 750 Kgs. 1100 Kgs
