INNER PROP WELDING MACHINE

0 out of 5 based on 0 customer ratings
(0 customer reviews)

Product Description

Automatic Inner prop welding machine is used to weld base plate with pipe without making any joint between them, It gives high production and accuracy to product. Inner prop is used with combination of Outer prop welding to make a structure. All the components are used in combination of each other Base jack welding machine, Inner prop welding machine, Outer prop welding machine, Cup lock welding machine, Ring lock welding machine.

This system is based on circular welding on both base plate with pipe and pipe with threaded sleeve from both positions as from top side or inside of sleeve for fastest production and uniform welding and it helps operator be safe from burning skin of continuous welding process. This unit is base on 380 -415 volts 50-60 hz. Ac as input supply and control led with Siemens make plc system and motor drive, clamping of job and de-clamping is pneumatically operated for movement of welding torches.

Specifications:-

Electric Supply Single Phase 220 Volt HZ 50/60
Speed 2 to 10 RPM
Motor Drive AC Inverter Type
Motor Type AC 220-Volts-3-Phase
Torch Clamping PNEUMATIC
Length Adjustment 150 to 2400 mm
Dimension L x W x H 11.3×2.5×5.3 (Foot)
